Savaria Concord Wheelchair Elevator Platform Porch Lift

Savaria Concord Lifts introduces the Multilift vertical wheel chair platform lift. The ACME screw drive system offers a safe and reliable operation for its users. This ruggedly constructed lift has been proven for both indoor and outdoor applications. The Multilift vertical wheel chair platform lift is designed to meet today's safety code requirements like ASME A18.1 and CSA-B613 for residential use.

ACME Screw Drive System Keyed Control Station On Car 1 hp (0.75 kw) motor, 110 VAC 750 lb (340 kg) capacity 42" (1067 mm) high platform guard panels 110 VAC operation (up and down) Approximate rate of speed 8 ft/min (0.04 m/s) Roller guide shoes Continuous pressure buttons on car Non-skid platform surface Manual emergency lowering/raising device Standard "Almond Beige" color Automatic Safety ramp on platform Platform safety underpan sensor Emergency stop on car Crating and handling

Application Residential user complies with ASME A18.1 and CSA-B613 Rated Load 750 lbs (340 kg) Rated Speed 8 ft./ min. (0.04 m/s) Usable Car Dimensions 34"W x 54"L (864 x 1,372 mm) Levels Serviced 2 # of Openings 2 Car Access Front/rear or 90 degree exit Maximum Travel 48" (1,219 mm) or 72" (1,827 mm) Operations Constant pressure Drive System ACME screw and back-up nut Power Supply (North America) 120 VAC, 20 AMPS, 1 PHASE, 60 Hz Controller Electronic-free relay logic Side Guard Panels 42" (1,067 mm) with metal inserts

Brochure User Manual Specifications CAD Drawings CAD Drawings - Doors and Gates

SAVARIA CONCORD MULTILIFT WHEELCHAIR ELEVATORS FOR HOME, PORCH, SCHOOL AND STAGE.  RESIDENTIAL AND COMMERICAL PACKAGES.  ADA AMERICAN'S DISABILITIES ACT PACKAGES.

Now for the first really new advances in electric wheelchair elevators and lifts for porch, mobile homes, schools,  . . . the incredible Concord Saveria MultiLift.  Use with unbelievable ease.  The time you can enjoy your day has a lot to do with the way you feel.  The Multi Lift so easy to use, you are going to enjoy each and everyday you can now have access to the full benefits of your wheelchair or scooter.  Concord Savaria Multi-Lift is designed to elevate and lower you and your wheelchair or scooter at the simple touch of your finger, making the time you can enjoy your day, more fullfilling.. Please call for  1(800)354-5040 FOR COMPLETE PRICE (there are many questions and options - please talk to an authorized specialist.
